Canon imagePROGRAF TC-20

Get cost effective, professional prints with Canon imagePROGRAF TC-20, a simple-to-use 24″ desktop printer, in small offices, retail shops, education or even work from home.

  • 4-colour
  • 70ml plastic ink bottle
  • Compact size
  • Built-in Auto sheet feeder
  • Shaftless roll holder
  • Hybrid support
  • EPEAT Gold rating1
SEND AN ENQUIRY
Categories: ,
Features & Benefits

Features & Benefits

Affordable high quality

Make most of the space you have in small offices, retail shops, education or work from home, with high-quality pigment ink and simple-to-use desktop printer without price tag, that can sit unobtrusively on your desk or shelves.

Easy Operation

Take the hassle out of print with this full front access device. A shaftless roll holder makes it easy to set up roll paper, while built-in auto-sheet feeder keeps your prints continuous without intervention in switching paper.

Hybrid support

Switch easily between home and office printing. The imagePROGRAF TC-20 shares software with your office-based imagePROGRAF devices, making hybrid working even easier.

Green at heart

Meet your sustainability goals with easily recyclable plastic 70ml ink bottles to minimize replacement, reduced packaging and an EPEAT Gold1 rated for low energy consumption.

SPECIFICATIONS

SPECIFICATIONS

Printer Technology

Printer Type 4 Colour 24″
Print Technology Canon Pigment ink 4 colours integrated type (4 chips per print head x 1 print head)
Print Resolution 2,400 x 1,200 dpi
Number of Nozzles Total : 4352 nozzles  BK : 1280 nozzles  C, M, Y : 1024 nozzles each
Line Accuracy ±0.1% or less
User adjustments necessary. Printing environment and media must match those used for the adjustments.
Nozzle Pitch 1,200 dpi x 2 lines
Ink Capacity Bundled Starter Ink: 280ml (70mlx4 for BK, C, M, Y)
Sales Ink: 70ml (BK, C, M, Y)
Ink Type Pigment inks : 4 colour  BK/C/M/Y
OS Compatibility 32 Bit: Windows7, Windows 8.1, Windows 10
64 Bit: Windows 7, Windows 8.1, Windows 10, Windows 11, Windows Server 2008R2, 2012, 2012R2, 2016, 2019, 2022
Apple Macintosh: macOS 10.14.6～macOS 12,x
Printer Languages SGRaster
Standard Interfaces USB A Port: N/A
USB B Port: Hi-Speed USB
Ethernet: IEEE802.3u(100BASE-TX) / IEEE802.3(10BASE-T)
Wireless LAN: IEEE802.11n/IEEE802.11g/IEEE802.11b

Memory

Standard Memory 1GB
Expansion slot : No
Hard Drive N/A

Print Speed

CAD Drawing Plain paper (A1, B&W):
0:33 (Standard)Plain Paper (A1, Colour):
1:03 (Standard)
Poster Plain Paper (A1):
1:10 (Fast)
2:08 (Standard)
Coated Paper (A1):
3:10 (Fast)
6:05 (Standard)

Media Handling

Media Feed and Output Roll Paper : One Roll, Front-loading, Front Output
Cut Sheet : Auto sheet feeder
Media Width Roll paper : 297mm – 610mm
Cut sheet: 210mm – 297mm
Media Thickness Roll/Cut : 0.08mm – 0.28mm
Minimum Printable Length Roll/Cut : 203.2mm
Maximum Printable Length Roll paper : 4m
Cut sheet : 432mm
Maximum Media Roll Diameter 110mm
Media Core Size Internal diameter of roll core: 2″
Margins Recommended Area Roll paper: Top: 5mm, Bottom: 5mm, Side: 5mm
(some photo mode: Top: 30mm, Bottom: 30mm)
Cut sheet: Top: 5mm, Bottom: 5mm, Side: 5mm
Margins Printable Area Roll paper: Top: 5mm, Bottom: 5mm, Side: 5mm
(some photo mode: Top: 30mm, Bottom: 30mm)
Cut sheet: Top: 5mm, Bottom: 5mm, Side: 5mm
Media Feed Capacity Roll Paper: One roll
Cut Sheet: 100 sheets(A4), 50 sheets (A3)
Media Take-Up Roll Unit N/A
Borderless Printing Width (Roll Only) N/A
Maximum Number of Delivered Prints Desktop Basket (BU-06): Standard position – 1 sheet

Power and Operating Requirements

Power Supply AC 100-240V (50-60Hz)
Power Consumption Operation: 28W or less
Sleep mode: 2.4W or less (using all ports)
Default setting for the time to enter the Sleep mode: Approx. 5 minutes
Power off: 0.3W or less
Operating Environment Temperature: 15~30℃, Humidity: 10~80% RH (no dew condensation)
Acoustic Noise (Power/Pressure) Operation: Approx. 42.5 dB(A) (Plain paper, Standard mode, Line Drawing/Text mode)
Standby: 35 dB(A) or less
(Measured on ISO 7779 standard)
Regulations CE mark, UKCA mark
Environment Certificates CB certfication, EPEAT GOLD1

Dimensions and Weight

Physical Dimensions and Weight W x D x H
Main Unit
968 x 545 x 395 mm (ASF Opened)
968 x 525 x 245 mm (ASF Closed)
32 kg (exclude ink bottle, include print head)Main Unit + Desktop Basket (BU-06)
968 x 825 x 965* mm (Basket Opened)
968 x 595 x 965* mm (Basket Closed)
33 kg (exclude ink bottle, include print head)
*Height above which cloth does not touch the floor when opening the desktop basketMain Unit + Stand + Basket (SD-24)
968 × 870 × 874 mm (Basket Opened)
968 × 707 × 874 mm (Basket Closed)
40 kg (exclude ink bottle, include print head)
Packaged Dimensions and Weight Printer (Main unit): 1120 x 726 x 406 mm, 43kg
Desktop Basket (BU-06): 798 x 301 x 111 mm, 1.8kg
Stand + Basket (SD-24): 1055 x 824 x 268 mm, 16kg

What’s Included

What’s in the Box? Printer, 1 Print head, Power Cable, 1 Set of starter ink tanks, Installation Guide, Safety/Standard Environment leaflet, EU Biocide Sheet, LFP Eur Address Sheet, Flange protective materials sheet
Software Included Software available as Download from Web

Options

Optional Items Desktop Basket: BU-06
Printer Stand + Basket: SD-24

Consumables

User Replaceable Items Ink Tank: PFl-050 (70ml)
Print Head: PF-08
Maintenance Cartridge: MC-32
