A unique solution for:
- Unique solution for short run jobs
- Automation of manual inserting
- Reprints processing
- Fast turn-around times
Plockmatic Reflex
Plockmatic Reflex is a modular concept offering maximum flexibility to meet most direct mail demands. Able to fill envelopes with up to 12 mm (0.5″) of documents. Can handle most envelope types – long edge or short edge flaps and from C4 down to DL type. Designed to handle up to 250 000 inserts per month. Active marketing entails communication and getting your message across to your target group.
Description
User friendly.
Our touch screen user interface features operator friendly settings with lightning fast job change-over. Using all the system’s features has never been easier. In fact, our operator training takes less than two hours of your time.
Automated change-over.
The Plockmatic Reflex offers an extensive range of compatible envelope sizes, from DL to B4.
Wide application range.
The Plockmatic Reflex offers an extensive range of compatible envelope sizes, from DL to B4. We also designed the Reflex to achieve a best in class filling thickness support for all of our customers applications.
Specifications
Specifications
Inserter
Cycle speed
4,000 / hr.
Envelope sizes (Min)
S65 / DL / #10
Envelope sizes (Max)
C4 / B4 / 10×13″
Envelope orientation
End and side seam flap
Envelope measurements (Min)
105×225 mm / 4.13×8.85″
Envelope measurements (Max)
353×353 mm / 13.9×13.9″
Document sizes (Min)
93×210 mm / 3.66×8.26″
Document sizes (Max)
300×315 mm / 11.81×12.4″
Insert thickness (Min)
300×315 mm / 11.81×12.4″
Insert thickness (Max)
12 mm / 0.47″
Tower Feeder
Feeders per tower
3 high capacity bins to 6 standard bins
Towers per system
1-2
Stack height standard bin (Max)
28 mm / 1.1″
Stack height High Capacity bin (Max)
70 mm / 2.75″
Sheet sizes (Min)
93×210 mm / 3.66×8.26″
Sheet sizes (Max)
300×315 mm / 11.8×12.4″
Paper weight (Min)
60 gsm
Paper weight (Max)
200 gsm
Booklet feeder thickness (Min)
1 pcs of 80 gsm
Booklet feeder thickness (Max)
8 mm / 0.31″
Accumulator / Folder
Sheet sizes (Min)
210×270 mm / 8.26×10.6″
Sheet sizes (Max)
300×300 mm / 11.8×11.8″
Fold capacity “C” / “Z”
7 sheets
Fold capacity Half-fold
10 sheets
Fold capacity based on 80 gsm sheets.
