Morgana Digicoater paper coating machine: 400 Cold UV or 400 LED-UV

Morgana Digicoater Pro 400 Cold UV and LED-UV Paper coating machine gives the perfect finish that enhances, protects and adds value to your printed sheets.

The Morgana DigiCoater Pro 400 CUV and 400 LED-UV Paper coating machine gives the perfect finish that enhances and protects your printed sheets. Environmentally friendly and with our unique curing process, this coating machine adds value to your printed sheet at a fraction of the cost of traditional laminating.

CUV and LED-UV Coating is widely considered as being a more environmentally friendly alternative to lamination as virtually no waste is produced in the production process. Unlike laminated stocks, which normally should be treated as plastic waste, CUV and LED-UV coated stocks can be disposed of, or recycled as normal printed paper would be.

Features and Benefits

Rub resistance – provides a more robust finish when the stock needs to be handled often, or pass through other finishing or mailing systems
High speed – up to 45m/m on Cold UV and LED-UV systems, with option to add 2nd lamp to increase speed
Suitable for inline and offline applications
Duplex coating option available
Optional automatic feeding and stacking units available
Lowest cost per sheet achievable on any machine in its class. Coated sheets are a fraction of the cost of laminated sheets.
Optional unique IR lamp system necessary for typical wax based toner.
Low coating coverage needed in order to complete the curing process, only 2 to 5g/m2
40% less power needed in order to cure compared to open lamp systems
Up to 45 metres per minute dependent on stock and type of print
Once coated, the stock is delivered at room temperature – so
there is limited distortion or shrinkage of the sheets.

Colours appear richer and more vivid

UV Coating is rapidly being adopted as a means to enhance, protect and add value to your digital and litho printed documents. The application of a gloss UV Varnish can be used enhance the print quality, making colours appear richer and more vivid, as well as offering protection for documents being frequently handled.

Specifications

Morgana DigiCoater Pro 400 CUV

Speed per min (CUV)

20-45 meters

Lamp technology

Enclosed Cold UV Quartz with contstant PLL controlled cooling

Lifetime Cold UV bulb or lamp

1,500 hours

IR Station

Optional

HD function

Optional

Applied coating

2-4 grams / square meter

Voltage

3 x 400 V + N + G (EU)

Amperage

20 amp – 400 V (EU) / 32 amp

Air knife

standard

Certifications

CE – ETL – UL/ULC (in progress)

Hot air extraction is needed

Morgana DigiCoater Pro 400 LED-UV

Speed per min (LED)

20-45 meters* (High speed option available*)

Lamp technology

Air Cooled LED

Lifetime LED

20,000 hours on diodes

IR Station

Optional

HD function / Module

Optional

Applied coating

2-4 grams / square meter

Voltage

3 x 400 V + N + G (EU)

Amperage

20 amp – 400 V (EU) / 32 amp

Air knife

Standard

Certifications

CE – ETL – UL/ULC (in progress)
