intaGlios M14/M20 | Gravure Cylinder

Electromechanical Gravure Cylinder Engraver (Rotogravure Cylinder Engraving Machine )

The intaGlios electronic engraver are designed to deliver the performance in gravure cylinder making.

  • 4kHz engraving speed
  • Easy Operation
  • Auto positioning of the engraving system
  • Robust design, simple operation
SEND AN ENQUIRY
Categories: ,
FEATURES & BENEFITS

FEATURES & BENEFITS

The intaGlios engravers (Rotogravure cylinder engraving machine) are an ideal, economical engraver for electromechanical cylinder engraving and is fully equipped to handle all types of jobs, including gravure cylinders for pantone, vignette, line work reproductions, and technical cylinders for transferring inks, coatings, and glues. The feature rich intaGlios engravers offer high quality strokes, which improves the appearance of fine text and graphics, and special software for sharper lettering.

Rotogravure cylinder engraving machineThe intaGlios engravers come with the speedy 4 kHz engraving system as standard with C Type engraving head but they are also compatible with Type B. The intaGlios operates depending on the type of engraving system in an effective screen range of 54 to 140 l/cm at a depth of up to 80 µm with either helical or polar line engraving. Freely definable screen angles are used.

Equipped with easy to use interface intaGlios helps the operator in job selection/test cut/engraving steps. Rotogravure cylinder engraving machine is also equipped with a motor motorized support and and Camera for clear dots view as standard for easy cell measurement.

  • 4kHz engraving speed
  • Easy Operation
  • Auto positioning of the engraving system
  • Robust design, simple operation
  • Low running cost
  • Camera for clear dots view
  • Direct TIFF workflow
  • Easy stylus changing
  • Operated and controlled by an integrated PC
  • Universal cones for shaft and hollow cylinders
  • Cell depth up to 80 μm
  • High ink volume in combination with engraving stylus angles from 95° -145°
Specifications

Specifications

M-14 M-20
Engraving Head German made German made
Cylinder Cirum (mm) 300 – 1400mm 300 – 1400 mm
Cylinder Length (mm) 200 – 1400 mm 200 – 2000 mm (Option up to 3200 mm)
Engraving Methods Helical, Polar line Helical, Polar line
Screen angle 0,2,3,4 0,2,3,4
Engraving speed R60: 0.38 m2/h / R70: 0.32 m2/h R60: 0.38 m2/h / R70: 0.32 m2/h
Engraving range 54-140l/cm 54-140l/cm
Cell Depth Upto 80 μm 80 μm
Engraving Frequency 4kHz/Sec 4kHz/Sec
Non-image Area Fast forward Fast forward
Software and Interface Windows 07/10 Windows 07/10
Stylus Support 95° to 145° with wing 95° to 145° with wing
Operation Temperature 18 – 25°C 18 – 25°C
Relative Humidity 20 – 80%, No water condensation 20 – 80%, No water condensation
Power Requirements AC 220V Single Phase, 50/60 Hz AC 220V Single Phase, 50/60 Hz
Current Consumption 1.8 KVA mean, 5KVA max 1.8 KVA mean, 5KVA max
Dimension (L xW x H) in mm 3500 x 1067 x 1524 3962 x 1067 x 1524
Weight 3000 kg approx. 4000kg Approx

Optional Attachment

  • Burr cutters
  • Art pro/ Planning Software
  • Full body cover
  • Type B : Screen 48 – 60 / Effective: 40 – 85 l/cm
  • Screen angles: Freely definable
